Fully Automated SMD Inductor Production Line

SMT Inductor Line

Engineered for high-volume production of SMD power inductors, this fully automated production line integrates precision winding, magnetic core assembly, resistance welding, performance inspection, and automated packaging processes to enable complete end-to-end manufacturing. The line delivers stable and efficient operation, improving product consistency and production efficiency, and is widely used for mass production of various SMD power inductor components.

Product Details

Process Detail 01
Process Detail 02

Advantages

01
Integrates winding, magnetic core assembly, welding, inspection, and packaging processes for complete automated manufacturing.
02
Precision winding control ensures stable coil processing and improves product parameter consistency.
03
Automated magnetic core assembly enhances positioning accuracy and supports high-volume production requirements.
04
Integrated resistance welding technology provides reliable connections and improves process stability.
05
In-line inspection enables real-time quality monitoring and improves process control.
06
Automated packaging optimizes downstream operations and enhances overall manufacturing efficiency.
07
Modular production line design enables coordinated multi-process operation and improves equipment utilization.
08
Stable automated operation reduces manual intervention and improves consistency in mass production.
09
Suitable for high-volume manufacturing of various SMD power inductor components.

Equipment Parameters

Model WM1-001 / WM4-30 / WM10-30
Spindle Number 1 / 4 / 10
Spindle Speed (rpm) 3000
Spindle pitch 30
Spindle Servo Motor Power (W) 400
Motor power A:200, B:200, C:1500, D:200
Winding core range Varies by process
Wire Range (mm) φ0.04-φ0.2mm
Wire number Single wire & bifilar wire
Efficiency (UPH) Efficiency varies with wire diameter, turns and process
Loading & Unloading Automatic carrier transfer mode
Controller JHY-3
Power Voltage Single-phase 220V, 50/60Hz
Air Pressure (MPa) 0.45-0.55
Program Storage ≤100
Machine Size (mm) 1000(L)*1000(W)*1800(H) | 1300(L)*1300(W)*1800(H)
Machine Weight (kg) 300kg / 600kg / 1200kg
